NET VIDEO RECORDER 16CH 16POE/NVR5216-16P-I/L DAHUA
Saņem no 14.05. līdz 20.05.
1759,66 €
16 IP channel max, up to 24MP resolution
Record Rate 320 Mbps (160 Mbps when AI function enabled)
VGA/HDMI up to 3840×2160 output
16-ch synchronous playback
2 SATA interfaces, up to 10 TB for a single HDD, Gigabit LAN
PoE: Max 25.5W for single port, 130W total rated power, 80% control for protection, 16 ports (IEEE802.3af/at), 1-8 PoE Ports support ePoE & EoC
Up to 4 Channel video metadata, Up to 12 Channel perimeter protection, SMD Plus, Up to 4 Channel video stream face recognition, Up to 16 face pictures/sec processing, Up to 20 face databases with 200,000 face images in total
No front panel controls, 4/2 alarm I/O, RS232, RS485, 2 USB
1U 19” chassis, mouse included
Free IP monitoring software available
Other brands IP cameras supported: Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, etc., ONVIF Version 2.4 conformance
Noliktavā 2 prece/-es
16 IP channel max, up to 24MP resolution
Record Rate 320 Mbps (160 Mbps when AI function enabled)
VGA/HDMI up to 3840×2160 output
16-ch synchronous playback
2 SATA interfaces, up to 10 TB for a single HDD, Gigabit LAN
PoE: Max 25.5W for single port, 130W total rated power, 80% control for protection, 16 ports (IEEE802.3af/at), 1-8 PoE Ports support ePoE & EoC
Up to 4 Channel video metadata, Up to 12 Channel perimeter protection, SMD Plus, Up to 4 Channel video stream face recognition, Up to 16 face pictures/sec processing, Up to 20 face databases with 200,000 face images in total
No front panel controls, 4/2 alarm I/O, RS232, RS485, 2 USB
1U 19” chassis, mouse included
Free IP monitoring software available
Other brands IP cameras supported: Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, etc., ONVIF Version 2.4 conformance
Specifikācija |
|
| Number of Channels | 16 |
| Number of drives/bays | 2 |
Mounting Type |
|
| Desktop/pedestal | Yes |
Interface |
|
| SATA | Yes |
Input/Output connectors |
|
| 15pin D-sub | 1 |
| Alarm In | 4 |
| Alarm Out | 2 |
| Audio-In | 1 |
| Audio-Out | 1 |
| HDMI | 1 |
| RS232 | 1 |
| RS-485 | 1 |
| USB 2.0 | 1 |
| USB 3.0 | 1 |
| PoE ports | 16 |
| Dimensions | 375.0 × 327.4 × 53.0mm |
| Operating temperature range | -10°C to +55°C |
| Shipping box quantity | 1 |
Shipping/Package Box Dimensions |
|
| Shipping Box Depth | 45cm |
| Shipping Box Height | 42cm |
| Shipping Box Weight | 4kg |
| Shipping Box Width | 17cm |
| Unit Brutto Volume | 0.03213cubm |
| Unit Net Weight | 2.7kg |
| Unit Gross Weight | 4kg |
Channels 16|Drives/bays 2|Desktop/pedestal|SATA|1x15pin D-sub|1xHDMI|1xAudio-In|1xAudio-Out|1xRS232|1xUSB 2.0|1xUSB 3.0|1xRS-485|4xAlarm In|2xAlarm Out|Dim. 375.0 × 327.4 × 53.0mm|Temp. range -10°C to +55°C
| Svars | 4 kg |
|---|---|
| Dimensijas | 45 × 17 × 42 cm |
