– 16× gigabit PoE+ RJ45 ports, 2× gigabit non-PoE RJ45 ports, and 2× combo gigabit SFP slots
– High PoE power budget with up to 30 W for each PoE port and 250 W for all PoE ports*
– Working with IEEE 802.3af/at compliant PDs
– Plug and play, with no configuration and installation needed
– 802.1p/DSCP QoS enable smooth latency-sensitive traffic
– Durable metal casing and professional heat dissipation design ensure a wide operating temperature range (0–50 ?)
Specification |
|
| Model name | TL-SG1218MP |
Mounting Type |
|
| Desktop/pedestal | Yes |
| Rack | Yes |
| Primary port count | 16 |
Ports |
|
| 10Base-T / 100Base-TX / 1000Base-T | 16 |
Network standard |
|
| IEEE 802.1Q | Yes |
| IEEE 802.3ab | Yes |
| IEEE 802.3af | Yes |
| IEEE 802.3at | Yes |
| IEEE 802.3i | Yes |
| IEEE 802.3u | Yes |
| IEEE 802.3x | Yes |
| PoE+ ports | 16 |
| PoE power budget | 250Watts |
| Switching capacity | 36Gbps |
| Forwarding rate | 26.78Mpps |
| Dimensions | 440 × 180 × 44 mm |
| Shipping box quantity | 1 |
Shipping/Package Box Dimensions |
|
| Shipping Box Depth | 53cm |
| Shipping Box Height | 25cm |
| Shipping Box Weight | 3.03kg |
| Shipping Box Width | 8cm |
| Unit Brutto Volume | 0.0106cubm |
| Unit Net Weight | 2.4kg |
| Unit Gross Weight | 3.03kg |
Desktop/pedestal|Rack|16x10Base-T / 100Base-TX / 1000Base-T|IEEE 802.1Q|IEEE 802.3ab|IEEE 802.3af|IEEE 802.3at|IEEE 802.3i|IEEE 802.3u|IEEE 802.3x|PoE+ ports 16|PoE power budget 250 Watts|Switching capacity 36 Gbps|Forwarding rate 26.78 Mpps|Dimensions 440 × 180 × 44 mm|Unit Net Weight 2.4 kg
